EB-LINK Engineering Telecom-Grade 3-Meter FC/APC-FC/APC Single-Mode Single-Core Fiber Optic Patch Cable, LSZH Low Smoke Zero Halogen Flame-Retardant, for IDC Server Rooms And Data Centers

SKU : 100010665902

Availability : In stock
4.7
Weight : 0.038 kg
Length : 17.6 cm
Height : 1.2 cm

GHS 30.01

GHS 32.41

Order now and get it less than 12-18 days

Pickup from our office at up to 0.00 delivery fee.

Contact Us on 0244133328 for any enquiry or assitance in placing your order

Product Description

**Product Specifications:**

**Brand:** EB-LINK

**Product Name:** FC/APC-FC/APC Single Mode Simplex Fiber Optic Patch Cord

**Fiber Type:** Single Mode 9/125um

**Core Material:** Ceramic insert core

**Performance:** Insertion Loss ≤0.30dB, Return Loss ≥45dB

**Outer Sheath Material:** LSZH (Low Smoke Zero Halogen)

**Length:** 3-20 meters (custom lengths available)

**Cable Diameter:** 3.0mm

**Storage Temperature:** -40~85°C

**Insertion/Withdrawal Cycles:** ≥1000 times

**Flame Retardant Rating:** IEC60332-1-2

**Features:**

High-quality ceramic insert core with low insertion loss and high return loss

YOFC fiber core for stable high-speed transmission

LSZH outer sheath for mechanical strength, flame resistance, low smoke, and halogen-free properties

Seiko polishing with three strict production processes for precise fiber core polishing

Multiple quality tests to ensure excellent performance

Various interface options available: LC UPC, LC APC, SC UPC, SC APC, FC UPC, FC APC

Suitable for routers, switches, fiber optic modules, patch panels, etc.

**Additional Information:**

Detailed product breakdown diagram available for understanding each component's material, name, and structure

Dust cap included for protection

Customizable lengths and interface options for different fiber optic equipment

For more information, please visit [EB-LINK Optical Fiber Cable SM](http://www.eb-link.com).
