H3C (H3C) H9 Kit 2.5G Version, AP Panel Whole-House WiFi Set, 4 1500M Dual-Band Wireless APs + 9-Port PoE Router, for Hotels, Homestays, Enterprise Networking, 1-To Set

SKU : 100120579239

Availability : In stock
4.7
Weight : 1.83 kg
Length : 32.5 cm
Height : 22 cm

GHS 3,140.29

GHS 3,391.52

Order now and get it less than 12-18 days

Pickup from our office at up to 0.00 delivery fee.

Contact Us on 0244133328 for any enquiry or assitance in placing your order

Product Description

Brand: H3C

Specifications:

Installation: Already renovated and wired, in the process of renovation, waiting for wiring (direct replacement, effortless), one-time construction, long-term stability. Not renovated or wired (pre-layout).

Hard requirements: Broadband access, optical modem to be placed in the weak current box.

Network cable requirements: Recommended to use Cat5e, Cat6, Cat6a cables to fully utilize the equipment's maximum performance.

Crystal head: There are differences between Cat5e and Cat6 cables, not recommended to mix use as it may lead to production failure.

Steps:

1. Clean the dust inside the panel box to avoid affecting heat dissipation and reducing equipment performance.

2. Insert the pre-reserved crystal head into the AP's back network port.

3. Install the AP with connected network cables into the 86 box.

4. Install all APs, configure the AC, ensure APs are functioning properly.

5. Screw on the screws, put on the protective cover, installation is complete.

POE Central Parameters:

1 reset switch

1 10/100/1000/2500Base-T Ethernet WAN port, switchable to LAN port

2 10/100/1000Base-T Ethernet LAN/WAN ports, standard PoE power supply

6 10/100/1000Base-T Ethernet LAN ports, standard PoE power supply

Dimensions (W×D×H): 227mm×55mm×23mm

POE power: 70W

Power supply: External, 54VDC 1.5A

Weight: ≤0.4kg (body)

Wireless AP Parameters:

Upstream port: 1 10/100/1000Base-T Ethernet upstream port

Downstream port: 1 10/100/1000Base-T Ethernet downstream port

Wireless rate: 1500Mbps (2.4G: 2*2 MIMO, 5G: 2*2 MIMO)

POE: Supports 802.3af/802.3at compatible power supply

Dimensions (W×D×H): 86mm*86mm*34.65mm

Power consumption: 7.5W

Weight: 0.12kg (body)
