H3C S1850V3-28P-EI 24-port Gigabit Ethernet + 4-port Gigabit SFP Managed Layer 2 Enterprise Network Switch with Visual Management/IPv6/Aggregation/VLAN

H3C S1850V3-28P-EI 24-port Gigabit Ethernet + 4-port Gigabit SFP Managed Layer 2 Enterprise Network Switch with Visual Management/IPv6/Aggregation/VLAN

SKU : 4060293

Availability : In stock

4.7

Weight : 2.85 kg

Length : 52.8 cm

Height : 10.8 cm

GHS 1,759.26

GHS 1,900.00

Order now and get it less than 12-18 days

Pickup from our office at up to 0.00 delivery fee.

GHS 1,759.26

GHS 1,900.00

Order now and get it by 12-18 days

Pickup from our office at up to 0.00 delivery fee.

Product Description

**Product Specifications:**

**Brand:** H3C

**Series:** S1750 Series, S1850V3 Series, S5000PV6-EI Series

**Features:**

- Support for LiteWare-based plug-and-play for easy and intelligent deployment

- Support for CLI command line and Web management

- Support for management and maintenance through Web interface

- Support for TELNET, FTP, DNSCLINET

- VLAN segmentation for port configuration

- TFTP for remote device upgrades

- Cloud management and Web cloud management

- Stackable design

**Port Types:**

- Multiple specifications available, including all Gigabit Ethernet ports, all Gigabit Ethernet ports + optical ports

**Power Supply:**

- Built-in AC power supply with AC input

**Switching Capacity:**

- 96Gbps to 128Gbps for S1750 Series

- 502Gbps/5.02Tbps for S1850V3 Series

- 596Gbps/5.96Tbps for S5000PV6-EI Series

**Forwarding Rate:**

- 54Mpps to 72Mpps for S1750 Series

- 78Mpps to 112Mpps for S1850V3 Series

- 96Mpps to 144Mpps for S5000PV6-EI Series

**Applications:**

- Suitable for network deployment in government, small enterprises, commercial chains, vocational education, security monitoring, and hotel industries

**Additional Information:**

- S1850V3-28P-EI model with 24 Gigabit Ethernet ports and 4 Gigabit optical ports

- Supports VLAN division, security policies, and green energy efficiency

**Technical Specifications:**

- Switching Capacity: 502Gbps/5.02Tbps

- Forwarding Rate: 96Mpps

- Management Ports: 1 Console

- Fixed Ports: 24*10/100/1000Base-T Ethernet ports, 4*1000Base-X SFP optical ports

- Support for various Ethernet features such as MDI/MDI-X, flow control, EEE, etc.

- Security features include MAC address learning limits, SSL, web page configuration, etc.

- Network management and monitoring through FTP, TFTP, Xmodem, SFTP file downloads, SNMP, etc.

- Operating temperature: -5~50℃

- Power consumption: ≤22W

- Weight: ≤2.1kg

- Input voltage: AC 100V~240V, 50/60Hz

- Dimensions: 440mm×160mm×43.6mm (L×W×H)

**Web Interface Login Guide:**

- Connect computer to device port using Ethernet cable

- Set computer IP to same subnet as device

- Access device default IP through browser (recommended: Google Chrome or IE)

- Default IPs: Router - 192.168.1.1, Firewall - 192.168.1.1, Switch - 192.168.0.233, MINI Wireless AP - 192.168.1.100, Small AP - Management address: 10.40.94.1

For more information on optical module options and purchasing, please click "Learn More".
