Ruijie (Ruijie) 5-Port 100Mbps Unmanaged Lightning-Proof Switch RG-YS05 Full-Speed Switching Data Stable Plug-And Home Business Dormitory Monitoring Switch Splitter

SKU : 100094027689

Availability : In stock
4.7

Write your review

Weight : 0.12 kg
Length : 8.7 cm
Height : 5.8 cm

GHS 75.62

6.98

Order now and get it less than 12-18 days

Pickup from our office at up to 0.00 delivery fee.

Contact Us on 0244133328 for any enquiry or assitance in placing your order

Product Description

**Product Specifications:**

**Brand:** Ruijie

**Quality:** Uncompromising quality, worry-free performance, providing stable happiness

**Compliance:** Strictly compliant with GB4943.1-2022 standards

**Data Transmission:** More stable data transmission, with a lightning protection capability of 4kV

**Lightning Protection Design:** High-spec lightning protection design to enhance network stability

**Plug and Play:** Zero configuration, plug in and use immediately

**Adaptive Ethernet Interface:** No configuration required, plug and play

**Port Expansion:** Easily expand network ports for various scenarios such as home, office, surveillance, etc.

**Compact Design:** Lightweight and compact design, suitable for various environments

**Product Model:** RG-YS05

**Technical Parameters:**

- **Fixed Interfaces:** 5 x 10/100Mbps adaptive Ethernet interfaces

- **Switching Capacity:** 1Gbps

- **Packet Forwarding Rate:** 0.75Mpps

- **MAC Table Entries:** 2K

- **Layer Type:** Unmanaged switch

- **Static MAC Address:** Not supported

- **MAC Address Filtering:** Not supported

- **Dimensions:** 85mm x 52mm x 23.5mm

- **System Indicator Lights:** Supported

- **Power Switch:** Not supported

- **Reset Button:** Not supported

- **Weight:** 50g (excluding packaging)

- **Installation:** Desktop or wall mount

- **Management Port:** None

- **Hot-swappable Cables:** Supported

**Power:**

- **Power Supply:** Adapter powered

- **Maximum Power Consumption:** ≤1.5W

- **Adapter AC Input:** Rated voltage range: 200V-240V~, Maximum voltage range: 180V-264V~, Frequency: 50Hz/60Hz

- **Adapter DC Output:** Rated voltage: 5V, Rated current: 1A

- **Energy Efficiency (EEE):** Not supported

**Operating Environment:**

- **Operating Temperature:** 0°C~40°C

- **Storage Temperature:** -40°C~70°C

- **Operating Humidity:** 10%~90% non-condensing

- **Storage Humidity:** 10%~90% non-condensing

**Lightning Protection:**

- **Port:** Common mode ±4kV, Differential mode ±2kV

- **Power:** Common mode ±2kV

**Certifications:** Network access certificate, safety regulations GB4943.1-2022
